CATEGORY:

Dimensional Measuring Instruments

Filter results by:
image description

Leap ST - Handheld 3D Scanner

FARO

view
x

View PDF Download PDF
View Demo
A Leap Forward in Handheld Scanning for Manufacturing and 3D Metrology Applications. Benefits: Accurate results, less time with less delay. Scan Faster with maximum versatility. HIGHLIGHTS • Ensure reliable measurement with the versatility to select from five operating modes • Accelerate inspection without sacrificing accuracy • Inspect more parts without increasing your cost-of-quality • Catch more defects to reduce scrap and maximize production uptime • Gather more data on production process trends to optimize quality Specifications Scan Mode Ultra-fast Scanning 34 blue laser lines Hyper Fine Scanning 7 blue parallel laser lines Large-area Scanning 11 parallel infrared laser lines Deep Hole Scanning 1 blue laser line Volume Accuracy Work Alone* 0.015 mm + 0.030 mm/m (0.0006 in + 0.00036 in/ft) Work With 1 m Reference Bar* 0.015 mm + 0.020 mm/m (0.0006 in + 0.00024 in/ft) Photogrammetry System Scanning Area 3760 mm x 3150 mm (148.0 in x 124.0 in) Depth of Field 2500 mm (98.4 in) * Based on the VDI/VDE 2634 Part 3 standard Technical Specifications Accuracy Up to 0.020 mm (0.0008 in) Scanning Rate up To 4,150,000 measurement/s Scanning Area up To 1440 mm x 860 mm (57.0 in x 33.9 in) Laser Class CLASS II (eye-safe) Resolution up To 0.010 mm (0.0004 in) Stand-off Distance 300 mm (11.8 in) Depth of Field up To 925 mm (36.4 in) Output Formats .asc, .igs, .txt, .stl Operating Temperature Range Minus 10˚ C - 40˚ C (14˚ F - 104˚ F) Interface Mode USB 3.0
Add to Enquiry
Buy Now
image description

Shop Floor CMM - MiSTAR

MITUTOYO

view
x

View PDF Download PDF
View Demo
MiSTAR 555 is a highly environment-resistant Coordinate Measuring Machine, allowing on-site Inspection outside the measuring room. Features
  • It has achieved an accuracy guaranteed temperature range of 10 to 40ºC thanks to the combination of technologies such as a symmetric structure, uniform material and temperature compensation.
  • The adoption of the horizontal-arm structure provides a three-sided open architecture, significantly easing the task of moving workpieces on and off the measuring table.
  • The touch panel and work positioning pallet make it easy for field workers to perform measurements.
  • It allows on-line monitoring of the operational status of a measuring machine and visualization of measurement data produced during the manufacturing process to enable product quality improvement.
Add to Enquiry
Buy Now
image description

"New" Quantum Arm X Series

FARO

view
x

View PDF Download PDF
View Demo
The Next Level of Probing and Scanning Accuracy Designed to probe or scan, articulated measurement arms are significantly more adaptable than bulkier fixed CMMs. They can access hard-to-reach locations, require less technical expertise to operate and help accelerate assembly workflows. 15% Accuracy Increase in All arms series boast up against previous models The addition of the FARO® 8-Axis Max, an 8-axis rotary worktable reduces measurement time by up to 40% while maintaining exceptional accuracy. Quantum X.S Premium Accuracy and Performance. This flagship arm has set the industry performance bar high and brings measurement consistency to every working environment. Manufacturers rely on the Quantum X.S FaroArm to stay ahead of their competitors through better quality assurance and customer confidence. Quantum X.M Optimized Price/Performance Balance.  This portable CMM is the standard for robust, reliable factory inspection. With an excellent price/performance ratio, the Quantum X.M FaroArm extends manufacturing performance through high-end quality inspection technology. Quantum X.E Great Performance with Greater Affordability Reliable and cost-effective, this portable CMM gives manufacturers full confidence in their quality assurance processes and ensures high quality production.
Add to Enquiry
Buy Now
image description

QuantuMike - High Speed Micrometer

MITUTOYO

view
x

View PDF Download PDF
View Demo
" New" QuantuMike - High Speed and High Accuracy This is an IP65 micrometer offering movement four times as fast as a standard micrometer. It presents you with the following benefits:
  • Faster measurement is achieved by using a coarser thread which feeds the spindle by 2 mm per thimble rotation.
  • Extraordinary battery life of 2,4 years
  • Outstanding accuracy
  • Ratched thimble mechanism ensures easy single-handed or stand operation. Excellent resistance against water and dust (IP65 protection level) enables this micrometer to be used in machining situations that include splashing coolant fluid.
Product Video
Add to Enquiry
Buy Now
image description

Digimatic Indicator ID-CNX

MITUTOYO

view
x

View PDF Download PDF
View Demo
The ABSOLUTE Digimatic Indicator ID-CNX series offers you the following benefits:
  • The ABSOLUTE sensor means you don‘t have to carry out origin setting every time you power it on, saving you time and hassle.
  • GO/±NG judgement is performed by setting the upper and lower tolerances.
  • You can make simple calculations by a user-definable factor using the formula Ax (‚x‘ is spindle displacement).
  • Large character height of 11mm provides good readability.
  • Display 330° rotatable.
  • A function lock protects the display against unauthorized use.
Add to Enquiry
Buy Now
image description

Coating Thickness Gages

DEFELSKO

view
x

View PDF Download PDF
View Demo
Coating Thickness Gages DF6000 Features : * Fast measurement speed—60+ readings per minute. Enhanced FAST mode— 90+ readings per minute for quick inspection. * Ready to measure—no adjustment required for most applications * NEW Larger 2.8” impact resistant color touchscreen with redesigned keypad for quick menu navigation * NEW On-gage help explains menu items at the touch of a button. * Flashing display—ideal in a noisy environment * RESET feature instantly restores factory settings. Durable * NEW Weatherproof, dustproof, and water-resistant—IP65-rated enclosure * NEW Ergonomic design with durable rubberized grip * Wear-resistant probe tip * Shock-absorbing protective rubber holster for added impact resistance. * Two-year warranty on gage body AND probe Accurate * Certificate of Calibration showing traceability to NIST or PTB included. * Built-in temperature compensation ensures measurement accuracy * Hi-RES mode increases displayed resolution for precision applications * Conforms to national and international standards including ISO and ASTM
Add to Enquiry
Buy Now
image description

Deep Throat Digital Thickness Gauge

MITUTOYO

view
x

View PDF Download PDF
View Demo

Deep Throat Flat Anvil Digital Thickness Gauge,

Metric, Range: 0 to 10 mm

Reach for this thickness gauge to take accurate measurements. The gauge features a deep throat and ceramic spindle and anvil construction. Features
  • Great for taking a variety of measurements
  • Built with a grip handle, thumb trigger and spring-loaded spindle
  • Offers a deep-throat design
  • Spindle and anvil are made of ceramic for durability
  • Measures from 0 to 10 mm with <1.4 N of force
Add to Enquiry
Buy Now
image description

Deep Throat Dial Thickness Gage

MITUTOYO

view
x

View PDF Download PDF
View Demo

Deep Throat Flat Anvil Dial Thickness Gauge,

Metric, Range: 0 to 10 mm

Reach for this thickness gauge to take accurate measurements. The gauge features a deep throat and ceramic spindle and anvil construction. Features
  • Great for taking a variety of measurements
  • Built with a grip handle, thumb trigger and spring-loaded spindle
  • Offers a deep-throat design
  • Spindle and anvil are made of ceramic for durability
  • Measures from 0 to 10 mm with <1.4 N of force
Add to Enquiry
Buy Now
image description

Digital Thickness Gauge

MITUTOYO

view
x

View PDF Download PDF
View Demo
Digimatic Thickness Gauge enables you to measure film, paper, etc., with flat contact points.
  • Bidirectional communication e.g. to perform parameter setting from a PC (Digimatic S 1 interface) is possible
Range : 0-10mm / 0.01mm
Add to Enquiry
Buy Now
image description

Dial Thickness Gage

MITUTOYO

view
x

View PDF Download PDF
View Demo

Dial Indicator Thickness Gauge

Range: 0-10mm, 0,01mm,
Standard, Ceramic Contact Elements
This Dial Indicator Thickness Gauge enables you to measure tube wall thickness, film/paper etc. with flat contact points, resp. lens thickness or groove depth.
Add to Enquiry
Buy Now
image description

Digital Thickness Gauge - Lens Measurement

MITUTOYO

view
x

View Demo

Digital Thickness Gauge

Range: 0 to 10 mm

Enables you to measure film, paper, etc., with flat contact points, this digital thickness gauge features a measuring range of 0 to 10 mm, and a resolution of 0.01 mm.

Features
  • Designed for measuring the thickness of concavo-convex lenses and flat objects
  • The thickness of flat objects can be measured by replacing the anvil
Applications Ideal for measuring measure film, paper, etc.
Add to Enquiry
Buy Now
image description

Dial Thickness Gage - Lens Measurement

MITUTOYO

view
x

View PDF Download PDF
View Demo

Dial Thickness Gauge

Range: 0 to 10 mm

This dial thickness gauge is used for measuring the thickness of lenses. The spindle lifting lever allows you to see your measurement quickly and easily.

Features
  • Used to measure lens thickness with an accuracy of 15 μm
  • Spindle lifting lever offers easy inspection of your measurement.
  • Wide measuring range accommodates a variety of applications.
  • .
Add to Enquiry
Buy Now
