Ideal for field/laboratoryverification of pulse DC holiday detectorsSIZE:43 x 5 x 5 cm, (17" x 2" x 2") WEIGHT:476 g (1.05 lbs.)EASY OPERATION Step 1.Ensure that the ground lead is plugged into thePosiTestHHD Verifierand that the other end of the ground lead is connected to the ground lead of the high voltage holiday detector that is being verified.Step 2.Turn thePosiTestHHD Verifieron by pressing and releasing the power button. Once powered on, the verifier continuously monitors the voltage on the probe end of the verifier. The verifier will update the display when the probe is touching an exposed electrode of a holiday detector. The voltage displayed on the verifier should match the voltage displayed by the detector within the combined tolerance of both units. Verifier
Ideal for field/laboratoryverification of pulse DC holiday detectorsSIZE:43 x 5 x 5 cm, (17" x 2" x 2") WEIGHT:476 g (1.05 lbs.)EASY OPERATION Step 1.Ensure that the ground lead is plugged into thePosiTestHHD Verifierand that the other end of the ground lead is connected to the ground lead of the high voltage holiday detector that is being verified.Step 2.Turn thePosiTestHHD Verifieron by pressing and releasing the power button. Once powered on, the verifier continuously monitors the voltage on the probe end of the verifier. The verifier will update the display when the probe is touching an exposed electrode of a holiday detector. The voltage displayed on the verifier should match the voltage displayed by the detector within the combined tolerance of both units. Verifier
PosiTest HHD - High Voltage Holiday Detector is to detects holidays, pinholes and other discountinuities using pulse DC
Specifications :
Output Voltage Range 0.5 – 35 kV
Output Voltage Adjustment
0.5 kV – 1 kV: 10 Volt Steps
1 kV – 35 kV: 100 Volt Steps
Output Accuracy +5%
Pulse Duration 10 μs
Pulse Repetition Rate 30 Hz
Coating Thickness Range up to 20 mm (780 mils)†
Typical Battery Life
Based on selected voltage and load
Ø 12” Rolling Spring @ 10kV, 40 hrs.
Ø 40” Rolling Spring @ 10kV, 30 hrs.
Operating Temperature -20° to 60°C (-4° to 140°F)
PosiTest HHD - High Voltage Holiday Detector is to detects holidays, pinholes and other discountinuities using pulse DC
Specifications :
Output Voltage Range 0.5 – 35 kV
Output Voltage Adjustment
0.5 kV – 1 kV: 10 Volt Steps
1 kV – 35 kV: 100 Volt Steps
Output Accuracy +5%
Pulse Duration 10 μs
Pulse Repetition Rate 30 Hz
Coating Thickness Range up to 20 mm (780 mils)†
Typical Battery Life
Based on selected voltage and load
Ø 12” Rolling Spring @ 10kV, 40 hrs.
Ø 40” Rolling Spring @ 10kV, 30 hrs.
Operating Temperature -20° to 60°C (-4° to 140°F)
Coating Thickness Gages
DF6000 Features :
* Fast measurement speed—60+ readings per minute. Enhanced FAST mode—
90+ readings per minute for quick inspection.
* Ready to measure—no adjustment required for most applications
* NEW Larger 2.8” impact resistant color touchscreen with redesigned keypad
for quick menu navigation
* NEW On-gage help explains menu items at the touch of a button.
* Flashing display—ideal in a noisy environment
* RESET feature instantly restores factory settings.
Durable
* NEW Weatherproof, dustproof, and water-resistant—IP65-rated enclosure
* NEW Ergonomic design with durable rubberized grip
* Wear-resistant probe tip
* Shock-absorbing protective rubber holster for added impact resistance.
* Two-year warranty on gage body AND probe
Accurate
* Certificate of Calibration showing traceability to NIST or PTB included.
* Built-in temperature compensation ensures measurement accuracy
* Hi-RES mode increases displayed resolution for precision applications
* Conforms to national and international standards including ISO and ASTM
Coating Thickness Gages
DF6000 Features :
* Fast measurement speed—60+ readings per minute. Enhanced FAST mode—
90+ readings per minute for quick inspection.
* Ready to measure—no adjustment required for most applications
* NEW Larger 2.8” impact resistant color touchscreen with redesigned keypad
for quick menu navigation
* NEW On-gage help explains menu items at the touch of a button.
* Flashing display—ideal in a noisy environment
* RESET feature instantly restores factory settings.
Durable
* NEW Weatherproof, dustproof, and water-resistant—IP65-rated enclosure
* NEW Ergonomic design with durable rubberized grip
* Wear-resistant probe tip
* Shock-absorbing protective rubber holster for added impact resistance.
* Two-year warranty on gage body AND probe
Accurate
* Certificate of Calibration showing traceability to NIST or PTB included.
* Built-in temperature compensation ensures measurement accuracy
* Hi-RES mode increases displayed resolution for precision applications
* Conforms to national and international standards including ISO and ASTM
Measure conditions :
Relative humidity, air temperature, surface temperature, dew point temperature
and difference between surface and dew point temperature.
Large , easy to read, graphics LCD
Audio and visual alarm - indicates when climate conditions are unsuitable for painting.
Measure conditions :
Relative humidity, air temperature, surface temperature, dew point temperature
and difference between surface and dew point temperature.
Large , easy to read, graphics LCD
Audio and visual alarm - indicates when climate conditions are unsuitable for painting.
Dew Point Meter Logger (Positector)
Magnetic probe attaches to steel structures for monitoring climatic conditions.
Measures and records climatic conditions including: relative humidity, air temperature, surface temperature, dew point temperature, difference between surface and dew point temperatures, and wet bulb temperature.
Fast response, precision sensors provide accurate, repeatable readings
Environmentally sealed enclosure – weatherproof, dustproof, and shockproof — meets or exceeds IP65
Internal memory storage of 10,000 datasets (60,000 readings)
Conforms to ISO 8502-4, BS 7079-B4, ASTM D3276, IMO PSPC, SSPC-PA7 and US Navy NSI 009-32
Dew Point Meter Logger (Positector)
Magnetic probe attaches to steel structures for monitoring climatic conditions.
Measures and records climatic conditions including: relative humidity, air temperature, surface temperature, dew point temperature, difference between surface and dew point temperatures, and wet bulb temperature.
Fast response, precision sensors provide accurate, repeatable readings
Environmentally sealed enclosure – weatherproof, dustproof, and shockproof — meets or exceeds IP65
Internal memory storage of 10,000 datasets (60,000 readings)
Conforms to ISO 8502-4, BS 7079-B4, ASTM D3276, IMO PSPC, SSPC-PA7 and US Navy NSI 009-32
Non-destructively measures the moisture
content of concrete in accordance with
ASTM F2659
Standard Test Method for Preliminary Evaluation of Comparative Moisture Condition of Concrete, Gypsum Cement, and Other
Floor Slabs and Screeds. Using a Non-Destructive
Electronic Moisture Meter
Non-destructively measures the moisture
content of concrete in accordance with
ASTM F2659
Standard Test Method for Preliminary Evaluation of Comparative Moisture Condition of Concrete, Gypsum Cement, and Other
Floor Slabs and Screeds. Using a Non-Destructive
Electronic Moisture Meter
Concrete Moisture Meter - In Situ
Measure Relative Humidity and Temperature in Concrete Floor Slabs
The PosiTector CMM IS probes and free mobile app guides users through the ASTM F2170 documentation criteria. View and record readings directly with your Apple or Android smart device or PosiTector DPM Advanced gage
Easily collect and report relative humidity and temperature in concrete floor slabs in conformance with ASTM F2170
No need to open the hole or remove the cap. Probes remain powered on and broadcasting via Bluetooth while in situ for up to three weeks.
Reusable Smart Probes
Fast response precision sensors provide accurate, repeatable readings
Fast acclimation, reduced testing time
Combined sleeve and probe design simplifies the installation process and does not require consumables
Concrete Moisture Meter - In Situ
Measure Relative Humidity and Temperature in Concrete Floor Slabs
The PosiTector CMM IS probes and free mobile app guides users through the ASTM F2170 documentation criteria. View and record readings directly with your Apple or Android smart device or PosiTector DPM Advanced gage
Easily collect and report relative humidity and temperature in concrete floor slabs in conformance with ASTM F2170
No need to open the hole or remove the cap. Probes remain powered on and broadcasting via Bluetooth while in situ for up to three weeks.
Reusable Smart Probes
Fast response precision sensors provide accurate, repeatable readings
Fast acclimation, reduced testing time
Combined sleeve and probe design simplifies the installation process and does not require consumables
Conductivity probe specifically designed for ISO 8502-6,9
Displays test duration, sample temperature, conductivity (μS/cm) and
surface density (mg/m2 or μg/cm2)
Onscreen interface guides users through the Bresle test method
Automatic storage of a background (blank) measurement — handy when
performing multiple tests
Solvent, acid, oil, water and dust resistant—weatherproof
Shock-absorbing, protective rubber holster with belt clip
Two year warranty on gage body AND probe
Long Form Certificate of Calibration showing traceability to NIST included
Includes certified conductivity standard (calibration solution) to verify probe accuracy. Certificate included.
Automatic temperature normalization and sample temperature reporting
Conforms to national and international standards including ISO, NACE, SSPC,IMO and US Navy
Conductivity probe specifically designed for ISO 8502-6,9
Displays test duration, sample temperature, conductivity (μS/cm) and
surface density (mg/m2 or μg/cm2)
Onscreen interface guides users through the Bresle test method
Automatic storage of a background (blank) measurement — handy when
performing multiple tests
Solvent, acid, oil, water and dust resistant—weatherproof
Shock-absorbing, protective rubber holster with belt clip
Two year warranty on gage body AND probe
Long Form Certificate of Calibration showing traceability to NIST included
Includes certified conductivity standard (calibration solution) to verify probe accuracy. Certificate included.
Automatic temperature normalization and sample temperature reporting
Conforms to national and international standards including ISO, NACE, SSPC,IMO and US Navy
Wall thickness such as steel, plastic and more ultrasonic technology
Multiple echo probe (UTG M - optional)) thru paint models
without remove the coating measure metal thickness of a painted structure.
Standard and Advanced Models
Wall thickness such as steel, plastic and more ultrasonic technology
Multiple echo probe (UTG M - optional)) thru paint models
without remove the coating measure metal thickness of a painted structure.
Standard and Advanced Models
Adhesion Tester Accuracy Verification Kit
Ideal for checking the accuracy and operation of adhesion testers and is an important component in fulfilling both ISO and in-house
quality control requirements.
EASY OPERATION
Connect the adhesion tester’s pull-off actuator to the PosiTest AT
Verifier’s loading fixture. Apply pressure using the adhesion tester’s
normal operating procedure. Compare values from the adhesion tester
and the Verification Device.
Adhesion Tester Accuracy Verification Kit
Ideal for checking the accuracy and operation of adhesion testers and is an important component in fulfilling both ISO and in-house
quality control requirements.
EASY OPERATION
Connect the adhesion tester’s pull-off actuator to the PosiTest AT
Verifier’s loading fixture. Apply pressure using the adhesion tester’s
normal operating procedure. Compare values from the adhesion tester
and the Verification Device.
